Description:
1, the interface shows the time (hour and minute) no date and seconds display, just show the time.
2, Rear MicroUSB a variety of placement, send a power cord, to hand plug any USB can be powered, you need to prepare their own charging head. Especially suitable for DIY collection (desktop clock, bedside sleep clock)!
3, built-in a button, open the Wi-Fi calibration function, 20 seconds to finish the calibration time.
4, Size 70X70X100 mm especially suitable for ornaments!
5, The new version adds time zone Settings

Wi-Fi clock instructions

The clock is controlled by pressing the key for different times. The details are as follows:

2: Timeline immediately.

3: Turn on the automatic time synchronization function every morning.

4: Turn off the automatic time synchronization function every morning.

5: Adjust the brightness, and the brightness oil will cycle from dark to bright.

6: Adjust the time to obtain the server without deliberate modification.

10: Restore factory settings.

For example, if you want to adjust immediately, press the key to display 2 and release,

If you want to adjust the brightness, just press the button to display 5 and let go.

Time synchronization mode: press and hold the key for 2 seconds, and the screen will release at 2 o'clock. The led indicator on the back of the clock will flash slowly to indicate that the time is being synchronized. If the time is successfully synchronized, the back indicator will be turned off.

If the timing fails, the led will change to flash, and the network needs to be configured manually.

Configure network:

When the indicator light on the back flashes quickly, turn on the Wi-Fi connection named WIFI_ Clock or VFD_ Clock's passwordless Wi-Fi. After connecting to this Wi-Fi, the networking interface can pop up normally. Enter the Wi-Fi name and Wi-Fi password, and then click "Save" in the lower left corner.

Including:
screen, driver board, control board, glass cover, the whole set of finished products shipped
